LW04-15

Pentagonal roller
EU Certificate
Technical sheet
/ Areas of activity
Electrical distribution
Transport
/ Accessories
LW08-03-TTD-100
LW08-03-C3T-100
LW14-05
TC53
/ Standards
Penta Bulletpoint IEC 60832-1
Penta Bulletpoint ASTM F711
/ Use
Ergonomic grip thanks to its pentagonal shape which follows the shape of the hand.
The roller tie is used as an intermediate insulating part in a device that allows tensile forces to be transmitted to a workpiece or conductor trapped in the tool head and supported by the roller.
The roller tie is also used as an intermediate insulating piece in a device that measures the distance of a conductor from the ground, another conductor or any other obstacle.
/ Technical specifications
Penta Bulletpoint Pulling undwinding devices : Pulling devices
Penta Bulletpoint Product type : Tirant
Penta Bulletpoint Operating voltage (V) : HTA (1 000 V to 50 000 V), HTB (> 50 000 V)
Penta Bulletpoint Ø of tube(s) : 32 mm
Penta Bulletpoint Clamping capacity (mm) : Max : 30 mm
Product reference CMU (daN) Isolating length Total length Weight (kg) Technical sheet Quantity
LW04-15-32P-150 450 1,10 m 1,50 m 2,0
Pulse 32 Darkbg
LW04-15-32P-210 450 1,70 m 2,10 m 2,5
Pulse 32 Darkbg
LW04-15-32P-390 450. 3,55 m 3,90 m 3,0
